用 途/Application:變頻電纜
（又名變頻電力電纜）廣泛應用于變頻器與電動機之間的電力線路上，實現電動機的無極調速。電纜的額定電壓為0.6 /1kV~3.6/6Kv,變化的變頻為0Hz~400Hz或0Hz~61Hz，使電動機的轉速由低速調到高速快速平衡的調制。
Power supply conversion cable is widely
used in power supply,circuit between frequency converter
and electric motor so as to realize stepless speed
regulation of electric motor.With rated voltage of
0.6/1kV ~3.6/6Kv, changing frequency from 0Hz to
400Hz or from 0Hz to 610Hz, the cable
Allows the rotational speed of electric motor to vary
from low to high quickly and steadily.
|
|
特征/characteristics：
變頻電纜的特征有三相主線芯和三條中性線芯對稱分布，
并有兩層屏蔽體，即內層總屏蔽和外層總屏蔽。
Power supply conversion cable has three-phase master
line cores and three neutral cores,which
array symmetrically,and has two shielding bodies,
namely, the inner layer general and outer
layer general shield.
|
|
結構示意圖/Structural schematic diagram of cable
型號及名稱/ Model and Description
|
型號Model
|
名稱Description
|
|
BPVVPP2
|
聚氯乙烯絕緣聚氯乙烯護套銅絲
編織內層總屏蔽銅帶外層總屏蔽變頻電纜。
PVC insulated，PVC sheathed，
copper braid inner layer collectively screened,
and copper tape outer layer collectively screened
power supply conversion cable.
|
|
BPYJVPP2
|
交聯聚氯乙烯絕緣聚氯乙烯護
套銅絲編織內層總屏蔽銅帶外層
總屏蔽變頻電纜。
XLPE insulated, PVC sheathed，
copper braid inner layer collectively screened, and
copper tape outer layer collectively screened power
supply conversion cable.
|
|
BPYJYPP2
|
交聯聚氯乙烯絕緣聚烯烴護套銅絲編織
內層總屏蔽銅帶外層總屏蔽變頻電纜。
XLPE insulated,PO sheathed，
copper braid inner layer collectively screened,
and copper tape outer layer collectively screened power
supply conversion cable.
|
|
WDZ-BPYJYPP2
|
交聯聚氯乙烯絕緣聚烯烴護套銅絲
編織內層總屏蔽銅帶外層總屏蔽
無鹵低煙阻燃變頻電纜。
XLPE insulated,PO sheathed， copper braid
inner layer collectively screened, opper tape
outer layer collectively screened，halogen-free,low-smoke and flame-retardant power supply conversion cable.
|
注：BP-變頻的漢語拼音開頭字母
Note:”BP” is the two initial letters of Chinese Pin Yin of conversion.
規格/Specification
|
相線芯標稱截面
Nominal cross-section Area of Phase Cores
(mm2)
|
中性線芯標稱截面
Nominal Cross-section Area of Neutral Cores
(mm2)
|
|
2.5
4
6
10
16
25
35
50
70
95
120
150
185
240
300
|
1
1,1.5
1.5,2.5
2.5,4,6
4,6,10
4,6,10
6,10,16
10,16,25
16,25,35
25,35,50
35,50,70,95
50,70,95,120
70,95,120
|
|
